Crystal Quest Thunder 500 GPD
Whole House Reverse Osmosis Water Filter
We recommend this model with a 220 gallon storage tank
for homes with 1 to 2 bath rooms
Our Whole House Reverse Osmosis System is
the highest performing RO System on the
market backed by more than 25 years of
experience. It has been designed and
engineered to provide purified water
throughout your entire home for many years
if properly maintained.
Every system is tested in-house before it is
shipped and arrives operational, requiring
minimal plumbing. As long as the prefilters
and membranes are changed regularly, these
systems should last from 15-20 years.
All our RO systems are designed to be
modular, require little operational
maintenance, and be economical. We
understand that this is a long-lasting
investment for both your family and home --
and we aim to make sure you are getting the
best possible return on your investment!
Endless Possibilities
It isn't always easy finding a perfect fit, but with 9 different
flow rates to choose from, we have a system that will meet your homes'
exact needs.
Storage Tank Kit Components
-
The RO System - A commercial-grade RO System
ranging from 200-7,000 GPD. Every system is equipped with
prefiltration to extend the life of the membranes.
-
Water Tank - Water is stored in an atmospheric
water storage tank (165, 220, or 550 gallons) that is sized
depending on your system.
-
Pump - As water is used within your home, it will
be pumped from the tank as needed.
-
Float Switches - Used within your water tank,
this regulates when your RO System needs to cut on and off depending
on the water level in your tank.
System Benefits
-
Compact, Space Saving
-
Easily Accessible
Components
-
Expandable and
Lightweight Design
-
Fully Equipped and
Customizable
-
Low Operational Costs
|
- Low cost of Maintenance
- Easily Maintenance and servicing
- Factory Tested and Preserved
- CE Compliant
- Made in the USA
|
Return to Reverse Osmosis Water Filters Page
Installation Manual
Optional Add-Ons
12 GPM UV Water Sterilizer
For added protection, we offer a premium UV
sterilizer to prevent microbiological
contamination.
Alkalizing Postfilter
Enhance the alkalinity of your water before
it enters your home with the added benefits
of a natural Alkalizing, Mineralizing, and
Oxidation Whole House filter.
Operating Specs*
|
Name |
Value |
|
Weight (lbs) |
50-265 |
|
Motor (hp) |
0-1.5 |
|
Voltage |
110V/220V* |
|
Hertz |
50 or 60 |
|
Feed Connection |
3/8" or 1" |
|
Product Connection |
3/8" or 1" |
|
Waste Connection |
1/4", 3/8", or 1" |
|
Min. Feed Pressure (psi) |
45 |
|
Min. NaCl Rejection |
96% |
|
Max. NaCl Rejection |
98.5% |
|
Min. Feed (gpm) |
1-10 |
|
Max. Hardness (grains/gallon) |
15 |
|
Max. TDS (ppm) |
1000-2000 |
|
Operating Pressure (psi) |
50-150 |
|
pH range |
3-11 |
Optional Upgrades:
All systems include a standard with a wide range of features. There
are various options and upgrades available to accommodate a diverse
range of water treatment applications. Listed below is a selection of
the most popular upgrades.
-
Stainless-Steel Rotary Vane Pump: Offers a longer
lifespan and increase resistance to high TDS feed water and
corrosive materials, such as dosing chemical and antiscalants.
-
Concentrate recycle valve: Allows for an increase
of RO systems efficiency by recycling back wastewater into the feed
stream and increasing the system recovery
-
SWP Digital Dual TDS Controller: Allow for
simultaneous monitoring of both feed TDS and permeate TDS levels,
helping to monitor the RO system salt rejection and membrane
performance.
-
SWP Digital TDS Controller: Allow for monitoring
either feed TDS and Permeate TDS levels
-
SWP Digital TDS/Conductivity Controller: Allow
for the monitoring of the RO permeate water TDS and conductivity
levels, useful in evaluating overall system performance IF Computer
Controller with feed flush: Allow for pre-treatment lockout
functionality, tank level input, features a convenient LED status
display indicator for increase ease of use.
-
S150 Computer Controller with Feed Flush: Allow
for pre-treatment lockout functionality, tank level input, features
a convenient LED status display and alarm function.
-
Chemical Pump Outlet: Provide an integrated power
source with the RO system for connection of a chemical feed pump.
-
Blending Valve: Allows for a mixture of feed
water into final RO permeate water to achieve desirable permeate
TDS.
-
Permeate Sample Port: Allows for evaluation of
individual membrane performance in on RO system and aids in system
troubleshooting and maintenance.
-
240V 50-60Hz or 110V 50-60Hz: Allow for selecting
sufficient voltage and hertz use requirement.
-
Single Wood Crate
Notes
All systems are rated with 77 Degree Farenheight water and TDS
(total dissolved solids) under 2000. Please refer to the specifications
of the exact system you plan to purchase. If your water falls outside of
these constraints, you should contact us for more recommendations
